| 产品特性：生物兼容 | 是否进口：否 | 产地：台湾 |
| 厂家(产地)：台湾奇美 | 牌号：PA-704LRP | 销售方式：品牌经销 |
| 类型：标准料 | 品名：医用级 | 加工级别：注塑级 |
| 特性级别：标准级 | 用途级别：医用级 | 品牌：奇美 |
| 产品规格：医用级 |
奇美PA-704 LRP医用级ABS塑胶原料生物兼容性，低单体残余量 (EU 10/2011 认证) 符合生物兼容性测试 (*** 10993 认证)。原厂原包，提供原厂质量检验证书(COA)，官方物性表等资料。
ABS PA-704LRP物性表：
| Physical | Nominal Value | Unit | Test Method |
Density (23°C) | 1.05 | g/cm? | *** 1183 |
Melt Volume-Flow Rate (MVR) (220°C/10.0 kg) | 17 | cm?/10min | *** 1133 |
Molding Shrinkage | 0.40 to 0.70 | % | *** 294-4 |
| Mechanical | Nominal Value | Unit | Test Method |
Tensile Stress (Yield) | 47.0 | MPa | *** 527-2/50 |
Tensile Stress (Break) | 34.0 | MPa | *** 527-2/50 |
Tensile Strain (Break) | 70 | % | *** 527-2/50 |
Flexural Modulus 2 | 2200 | MPa | *** 178 |
Flexural Stress 2 | 76.0 | MPa | *** 178 |
| Impact | Nominal Value | Unit | Test Method |
Charpy Notched Impact Strength | *** 179 | ||
-30°C | 10 | kJ/m? | |
23°C | 21 | kJ/m? | |
Notched Izod Impact Strength | *** 180/1A | ||
-30°C | 9.0 | kJ/m? | |
23°C | 19 | kJ/m? | |
| Thermal | Nominal Value | Unit | Test Method |
Deflection Temperature Under Load (1.8 MPa, Unannealed) | 83.0 | °C | *** 75-2/A |
Deflection Temperature Under Load (1.8 MPa, Annealed) | 98.0 | °C | *** 75-2/A |
Vicat Softening Temperature | |||
-- | 100 | °C | *** 306/B50 |
-- | 104 | °C | *** 306/A50 |
CLTE - Flow | 8.6E-5 | cm/cm/°C | *** 11359-2 |
| Flammability | Nominal Value | Unit | Test Method |
Flame Rating (1.5 mm) | HB | UL 94 |
