| 产品特性：抗微生物 | 是否进口：否 | 产地：上海 |
| 厂家(产地)：德国亨斯迈 | 牌号：A85P | 销售方式：品牌经销 |
| 类型：标准料 | 品名：TPU电缆料 | 加工级别：注塑级、 挤出级 |
| 特性级别：耐水解、 耐磨、 抗化学性 | 用途级别：通用级、 电线电缆级 | 品牌：亨斯迈 |
亨斯迈A85P抗微生物TPU电缆料，低温柔韧性，特 别适合生产电缆护套，型材，管材高压管护套。优 异的抗微生物性能。原厂原包，提供原厂质量检验证书(COA)，官方物性表等资料。
TPU A85P物性表：
| Physical | Nominal Value | Unit | Test Method |
Density / Specific Gravity 2 | 1.11 | g/cm? | ASTM D792 |
Density 2 | 1.11 | g/cm? | *** 1183 |
Melt Volume-Flow Rate (MVR) (190°C/21.6 kg) | 65 | cm?/10min | *** 1133 |
Molding Shrinkage - Flow (Injection Molded) | 0.50 | % | ASTM D955 |
Molding Shrinkage 2 | 0.80 | % | *** 294-4 |
| Mechanical | Nominal Value | Unit | Test Method |
Flexural Modulus | ASTM D790 | ||
-29°C, Injection Molded | 105 | MPa | |
23°C, Injection Molded | 52.3 | MPa | |
Abrasion 2 | 35 | mm? | *** 4649 |
| Elastomers | Nominal Value | Unit | Test Method |
Tensile Stress 3 (*** Strain) | 6.76 | MPa | ASTM D412 |
Tensile Stress 2 (*** Strain) | 7.30 | MPa | DIN 53504 |
Tensile Stress 3 (300% Strain) | 10.8 | MPa | ASTM D412 |
Tensile Stress 2 (300% Strain) | 11.0 | MPa | DIN 53504 |
Tensile Strength 3 | 48.0 | MPa | ASTM D412 |
Tensile Stress 2 (Break) | 40.0 | MPa | DIN 53504 |
Tensile Elongation 3 (Break) | 580 | % | ASTM D412 |
Tensile Elongation 2 (Break) | 650 | % | DIN 53504 |
Tear Strength 3 | 84.1 | kN/m | ASTM D624 |
Tear Strength 2 | 60.0 | kN/m | *** 34-1 |
Compression Set 2 | ASTM D395 | ||
23°C, 22 hr | 28 | % | |
70°C, 22 hr | 83 | % | |
Compression Set 2 | *** 815 | ||
23°C, 70 hr | 24 | % | |
70°C, 24 hr | 42 | % | |
Bayshore Resilience 2 | 44 | % | ASTM D2632 |
| Hardness | Nominal Value | Unit | Test Method |
Durometer Hardness | ASTM D2240 | ||
Shore A, 3 sec, Injection Molded | 87 | ||
Shore D, 3 sec, Injection Molded | 39 | ||
Shore Hardness | *** 7619 | ||
Shore A, 3 sec, Injection Molded | 87 | ||
Shore D, 3 sec, Injection Molded | 38 | ||
| Thermal | Nominal Value | Unit | Test Method |
Glass Transition Temperature 3 | -41.0 | °C | ASTM D3418 |
Vicat Softening Temperature 2 | 83.0 | °C | ASTM D1525 4 |
Softening Range 3 | Internal Method | ||
High | 175 | °C | |
Low | 155 | °C |
| Processing Information | |||
| Injection | Nominal Value | Unit | |
Drying Temperature | |||
Circulation Dryer | 100 to 110 | °C | |
Desiccant Dryer | 80 to 90 | °C | |
Drying Time | |||
Circulation Dryer | 3.0 | hr | |
Desiccant Dryer | 3.0 | hr | |
Dew Point | -30 | °C | |
Rear Temperature | 185 to 195 | °C | |
Middle Temperature | 185 to 195 | °C | |
Front Temperature | 185 to 195 | °C | |
Nozzle Temperature | 185 to 200 | °C | |
Mold Temperature | 20 to 50 | °C | |
| Injection Notes | |||
Feed Zone: 25 - 40°C | |||
| Extrusion | Nominal Value | Unit | |
Cylinder Zone 1 Temp. | 175 to 185 | °C | |
Cylinder Zone 2 Temp. | 175 to 185 | °C | |
Cylinder Zone 3 Temp. | 175 to 185 | °C | |
Cylinder Zone 4 Temp. | 175 to 185 | °C | |
Cylinder Zone 5 Temp. | 175 to 185 | °C | |
Adapter Temperature | 175 to 185 | °C | |
Die Temperature | 185 to 195 | °C |
