| 产品特性：耐水解 | 是否进口：否 | 产地：深圳 |
| 厂家(产地)：日本东丽 | 牌号：A604 WR | 销售方式：品牌经销 |
| 类型：标准料 | 品名：耐水解PPS | 加工级别：注塑级 |
| 特性级别：阻燃级、 增强级、 耐水解 | 用途级别：食品级、 汽车部件、 电子电器部件、 家电部件 | 品牌：日本东丽 |
| 产品规格：耐水解 |
东丽A604 WR耐水解PPS水应用认证，40%玻纤，水应用批准/认证，耐水解。原厂原包，提供原厂质量检验证书(COA)，官方物性表等资料。
PPS A604 WR物性表：
Features | Chemical ResistantDrinking Water Contact AcceptableFlame RetardantHigh Heat ResistanceHigh Strength |
Uses | FittingsPlumbing PartsValves/Valve Parts |
Processing Method |
|
*** Designation |
|
| ASTM & *** Properties 1 | |||
| Physical | Nominal Value | Unit | Test Method |
Density (23°C) | 1.66 | g/cm? | *** 1183 |
Spiral Flow 2 | 10.0 | cm | Internal Method |
Molding Shrinkage 3 | Internal Method | ||
Across Flow : 3.00 mm | 0.80 | % | |
Flow : 3.00 mm | 0.20 | % | |
Water Absorption 4 (24 hr, 23°C) | 0.020 | % | *** 62 |
| Mechanical | Nominal Value | Unit | Test Method |
Tensile Stress (23°C) | 188 | MPa | *** 527-2 |
Tensile Strain (Break, 23°C) | 1.8 | % | *** 527-2 |
Flexural Modulus (23°C) | 14500 | MPa | *** 178 |
Flexural Stress (23°C) | 280 | MPa | *** 178 |
| Impact | Nominal Value | Unit | Test Method |
Charpy Notched Impact Strength (23°C) | 9.0 | kJ/m? | *** 179 |
Charpy Unnotched Impact Strength (23°C) | 50 | kJ/m? | *** 179 |
| Hardness | Nominal Value | Unit | Test Method |
Rockwell Hardness (R-Scale) | 122 | *** 2039-2 | |
| Thermal | Nominal Value | Unit | Test Method |
Deflection Temperature Under Load (1.8 MPa, Unannealed) | > 260 | °C | *** 75-2/A |
Melting Temperature | 278 | °C | *** 11357-3 |
| Electrical | Nominal Value | Unit | Test Method |
Volume Resistivity | 1.0E+16 | ohms·cm | IEC 60093 |
| Flammability | Nominal Value | Unit | Test Method |
Flame Rating (0.200 mm) | V-0 | UL 94 |
