| 厂家(产地)：荷兰品牌 | 牌号：K223-HGM24 | 销售方式：品牌经销 |
| 类型：标准料 | 加工级别：注塑级 | 特性级别：增强级、 耐高温、 高流动 |
| 用途级别：填充级、 汽车部件、 纤维、 家电部件 | 品牌：荷兰品牌 |
供应荷兰品牌K223-HGM24玻纤+矿物增强PA6 尺寸稳定 含10%玻纤增强, 20%矿粉，尺寸稳定, 低翘曲，热稳定。
DISIMAN K223-HGM24物性：
| General | |
Material Status |
|
Availability | Africa & Middle EastAsia PacificEuropeLatin AmericaNorth America |
Filler / Reinforcement |
|
Additive | Heat StabilizerMold Release |
Features |
|
Uses |
|
Automotive Specifications |
|
Processing Method |
|
Resin ID (*** 1043) |
|
| ASTM & *** Properties 1 | ||||
| Physical | Dry | Conditioned | Unit | Test Method |
Density | 1.37 | -- | g/cm? | *** 1183 |
Molding Shrinkage | *** 294-4 | |||
Across Flow | 0.90 | -- | % | |
Flow | 0.30 | -- | % | |
Water Absorption (Saturation, 23°C) | 6.5 | -- | % | *** 62 |
Water Absorption (Equilibrium, 23°C, 50% RH) | 1.9 | -- | % | *** 62 |
| Mechanical | Dry | Conditioned | Unit | Test Method |
Tensile Modulus | 7500 | 3200 | MPa | *** 527-2 |
Tensile Stress (Break) | 110 | 50.0 | MPa | *** 527-2 |
Tensile Strain (Break) | 2.5 | 12 | % | *** 527-2 |
| Impact | Dry | Conditioned | Unit | Test Method |
Charpy Notched Impact Strength | *** 179/1eA | |||
-30°C | 5.0 | 5.0 | kJ/m? | |
23°C | 3.0 | 8.0 | kJ/m? | |
Charpy Unnotched Impact Strength | *** 179/1eU | |||
-30°C | 35 | 35 | kJ/m? | |
23°C | 40 | 45 | kJ/m? | |
| Thermal | Dry | Conditioned | Unit | Test Method |
Heat Deflection Temperature (0.45 MPa, Unannealed) | 210 | -- | °C | *** 75-2/B |
Heat Deflection Temperature (1.8 MPa, Unannealed) | 180 | -- | °C | *** 75-2/A |
Melting Temperature 2 | 220 | -- | °C | *** 11357-3 |
CLTE - Flow | 3.5E-5 | -- | cm/cm/°C | *** 11359-2 |
CLTE - Transverse | 6.0E-5 | -- | cm/cm/°C | *** 11359-2 |
Effective Thermal Diffusivity | 1.46E-7 | -- | m?/s | |
| Electrical | Dry | Conditioned | Unit | Test Method |
Volume Resistivity | 1.0E+14 | 1.0E+12 | ohms·cm | IEC 60093 |
Electric Strength | 35 | 30 | kV/mm | IEC 60243-1 |
Relative Permittivity | IEC 60250 | |||
100 Hz | 3.50 | 14.0 | ||
1 MHz | 3.30 | 4.50 | ||
Dissipation Factor | IEC 60250 | |||
100 Hz | 5.0E-3 | 0.32 | ||
1 MHz | 0.014 | 0.12 | ||
Comparative Tracking Index | -- | 500 | V | IEC 60112 |
| Flammability | Dry | Conditioned | Unit | Test Method |
Flammability Classification (1.6 mm) | HB | -- | IEC 60695-11-10, -20 | |
| Fill Analysis | Dry | Conditioned | Unit | Test Method |
Melt Density | 0.976 | -- | g/cm? | |
Melt Thermal Conductivity | 0.31 | -- | W/m/K | |
Specific Heat Capacity of Melt | 2180 | -- | J/kg/°C | |
订购说明
★公司秉承“以诚为本，信誉至上”的经营宗旨，【诚信***】【服务***】【品质***】创立了自己的经营理念，在客户群树立了良好的***。为您提供充足的货源和专业的技术支持！公司所售之新料均***原厂原包，货真价实!
★公司货源充足，品种齐全，价格合理,量大从优,原厂原包,当天订货当天发货。我公司可以提供原料出厂报告(COA)，认证报告;UL认证、FDA认证、材质证明、***，ASTM物性资料、ROHS(SGS)报告、物质安全资料表(MSDS)物性、报价、UL报告、RoSH标准、SGS检测报告等）......
★支持物流，快递和货运; 支持现金，银行转账（广东省内可快递代收）.
★原料到厂后，请不要拆外包装，应先仔细检查原料的外包装是否完好及原料型号是否与您所订购原料型号相匹配。
★货物送达后，请***时间检查，发现物流过程中出现大量包装损坏及原料外漏的,请让物流人员出具证明并保存，并在24小时内与东莞佳唯斯塑胶原料有限公司颜小姐联系。
★如发货后未能及时收到，请及时与东莞佳唯斯塑胶原料有限公司颜小姐联系15382847379
